Pipes, fittings,
flanges and valves

Produced by cold drawing and cold rolling, with full test facilities including PMI, eddy current and ultrasonic inspection. Stainless steel bright annealed pipes and tubing meet the requirements of pressure gauge, precision machine, medical device and loom applications. Specifications can be customised at your request.

• Cold drawn and cold rolled
• Stainless steel bright annealed
• Pipes and tubes
• Customer specifications quoted to drawing

Sizes, specifications and dimension tables →

Butt-welded pipe fittings, casting pipe fittings and forged pipe fittings with a maximum outside diameter of 64". Stainless steel and carbon steel alloys are available, seamless and welded at your option.

• Butt-welded, casting and forged
• Maximum OD up to 64"
• Seamless and/or welded
• Stainless steel and carbon steel

Dimensions by class and pattern →

Forged flanges and rings with pressure ratings up to class 2500 and sizes up to 60". Alongside common flanges we supply orifice flanges, long welding neck flanges, flange rings, figure 8 flanges, reducing flanges and blinds.

• Class 150 – 2500, sizes up to 60"
• In accordance with ASME/ANSI B16.5, MSS SP-6, 25 & 51
• ASTM/ASME A/SA-182 material
• Permanent identification
• Orifice, long welding neck, figure 8, reducing, blind

Dimensions, ratings and tolerances →

Stainless steel nipples made to ASTM A733 from ASTM A312 pipe. Standard nipples are threaded both ends, with other end combinations available to order.

• ASTM A733 from ASTM A312 pipe
• TBE — threaded both ends (standard)
• TOE, PBE and BOE combinations available
• SCH 40 / SCH 80 / SCH 160 / SCH XXS

Lengths and weight tables →

Ball, globe, check and gate valves in threaded, socket weld, flanged and butt weld connections, in stainless steel, carbon steel and brass.

• Ball / gate / globe / check
• Needle valves and strainers
• Threaded / socket weld / flanged / butt weld
• Stainless steel and brass

Dimensions, materials and part codes →

Stainless steel fasteners and hangers — bolts, screws, nuts and washers through threaded rod, pipe supports, strut components, wire rope and chain.

• Bolts, screws, socket and set screws; machine, tapping and self-drilling
• Nuts, washers, threaded rod, studs and eye bolts
• Pipe supports, clamps, straps and strut components
• Wire rope and chain with accessories
• 18-8 (300 series) and 410 stainless; 316 on request

Range, weight and bolt-up charts →

Parts stamped and formed on our own 1,500-ton press and tooling — two catalogue ranges, new for 2026, and custom parts to your drawing or sample.

• Roofing & exterior hardware — 16 items
• Poster frames & sign hardware — 44 items
• Custom parts to drawing or sample
• Stainless, carbon and spring steel; zinc plated, hot dip galvanized or powder coated
• Bagged with fixings, private label available

The stamping page: ranges, press and catalogues →
