| Full Port 200 WOG Swing Check Valve, Threaded |
• Pressure rating: 200 PSI WOG (NON-SHOCK)
• Steam Rating: 150 PSI WSP
• Investment cast body & cap
• Screwed cap
• Swing type disc
FULL PORT
200 WOG SWING CHECK VALVE, THREADED
| DIMENSIONS |
| CODES |
SIZE |
A |
L |
H |
Cv Factor |
Weight LB |
| inch |
mm |
inch |
mm |
inch |
mm |
inch |
mm |
| 13TCV025 |
1/4" |
8.0 |
0.39 |
10.0 |
2.56 |
65.0 |
1.77 |
45.0 |
- |
0.73 |
| 13TCV0375 |
3/8" |
10.0 |
0.47 |
12.0 |
2.56 |
65.0 |
1.77 |
45.0 |
4 |
0.68 |
| 13TCV05 |
1/2" |
15.0 |
0.59 |
15.0 |
2.60 |
66.0 |
1.81 |
46.0 |
6.5 |
0.64 |
| 13TCV075 |
3/4" |
20.0 |
0.79 |
20.0 |
3.19 |
81.0 |
2.13 |
54.0 |
15 |
1.08 |
| 13TCV1 |
1" |
25.0 |
0.98 |
25.0 |
3.58 |
91.0 |
2.36 |
60.0 |
28 |
1.52 |
| 13TCV125 |
1 1/4" |
32.0 |
1.26 |
32.0 |
4.19 |
106.5 |
2.83 |
72.0 |
45 |
2.32 |
| 13TCV15 |
1 1/2" |
40.0 |
1.57 |
40.0 |
4.76 |
121.0 |
2.95 |
75.0 |
65 |
3.48 |
| 13TCV2 |
2" |
50.0 |
1.97 |
50.0 |
5.59 |
142.0 |
3.23 |
82.0 |
120 |
5.16 |
| 13TCV25 |
2 1/2" |
65.0 |
2.56 |
65.0 |
6.26 |
159.0 |
3.54 |
90.0 |
180 |
8.38 |
| 13TCV3 |
3" |
80.0 |
3.15 |
80.0 |
7.48 |
190.0 |
4.09 |
104.0 |
280 |
13.01 |
| MATERIALS LIST |
| NO. |
PART NAME |
MATERIAL |
QTY |
| 1 |
BODY |
ASTM A351 Gr. CF8M |
1 |
| 2 |
CAP |
ASTM A351 Gr. CF8M |
1 |
| 3 |
DISC |
ASTM A351 Gr. CF8M |
1 |
| 4 |
HINGE PIN |
SS316 |
1 |
| 5 |
GASKET |
PTFE |
1 |
| 6 |
PLUG |
SS316 |
1 |
* SIZES SHOWN ARE APPROXIMATE AND MAY VARY |
|
|
|
